YF 2401
23.8-inch pen display
- 23.8" pen display, 1920x1080 Full HD
- 100% sRGB color gamut, vivid colors
- HDMI / DP / VGA multi-interface
- 8192 levels of pressure sensitivity
- 10-point capacitive touch
- Professional Podium Writing Screen
Technical data
Key specifications
Model YF 2401
| Item | Parameter | |
|---|---|---|
| LCD Display | Screen Size | 23.8 inch |
| Native Resolution | 1920 x 1080 | |
| Display Type | IPS LCD | |
| Active Area Size | 527.04 x 296.46 mm | |
| Contrast Ratio | 1000 : 1 | |
| Brightness | 250 cd/m2 | |
| Response Time | 14 ms | |
| Viewing Angle | 89°/89° (H)/(V) | |
| Gamut | 100% sRGB | |
| Display Color | 1.07B (8bit+H-FRC) | |
| Pad and Pen | Reading Technology | Battery-free Electromagnetic Resonance |
| Handwriting Resolution | 5080 LPI | |
| Pressure Levels | 8192 | |
| Coordinate Accuracy | ±0.5mm(Center), ±3mm(Corner) | |
| Reading Height | 10 mm | |
| Report Rate | 233 points per second | |
| Touch Input | Capacitive | 10 point finger touch |
| General | Power Input | 12V, 4A |
| Video Interface | HDMI, DP, VGA | |
| Net Weight | 6.4 KG | |
| Main Body Color | Black | |
| Dimension | 594.7 x 363 x 43.5 mm (without stand) | |
| OS Support | Windows 7+, macOS 10.12+ | |
| Power Consumption | 36W | |
